The Flusso Vertical Buffer Tank is the No. 1 solution for energy storage which can be utilized either in systems for direct production of Domestic Hot Water (DHW) (in-line water heating) when combined with FRESH WATER systems or in space heating/cooling systems, swimming pools and related applications.
| Tank body material | INOX 304 |
| Insulation | Polyurethane foam (thickness: 90-100 mm, density: 45 kg/m3) |
| Outer casing | PVC leather |
| Welding type | Automatic circular welding |
| Protection | Inactivation coating |
| Nominal operating pressure | 3 bar |
| Maximum operating pressure | 6 bar |
| Energy classification | A-B |
| Nominal operating temperature | 90oC |
Without solar heat exchanger
| TECHNICAL CHARECTERISTICS | |||||
| FLUSSO BF VER | 80 | 130 | 300 | 600 | 1000 |
| Volumetric capacity (lt) | 80 | 130 | 300 | 600 | 1000 |
| Height (mm) | 650 | 1200 | 1680 | 2020 | 2023 |
| Diameter (mm) | 440 | 440 | 690 | 810 | 1000 |
| Weight (kg) | 22 | 29 | 71 | 99 | 125 |
With solar heat exchanger
| TECHNICAL CHARECTERISTICS | |||
| FLUSSO BF VER–S | 300 | 600 | 1000 |
| Volumetric capacity (lt) | 300 | 600 | 1000 |
| Solar Heat Exchanger Area (m2) | 0.7 | 1.4 | 2.0 |
| Height (mm) | 1680 | 2020 | 2023 |
| Diameter (mm) | 690 | 810 | 1000 |
| Weight (kg) | 74 | 103 | 131 |
